Avaya C360 Front and Rear Panels
32 Installation and Configuration Guide Avaya C360 Multilayer Stackable Switches, version 4.5
The following Function LEDs apply to all ports
LNK
Port Status
OFF - Port is disabled
ON - Link is OK
Blinking - Port is enabled, but Link is down
COL
Collision
OFF - No collision or full-duplex port for ports 1 to
24/48; always OFF for ports 51 to 52.
ON - Collision occurred on line.
Tx
Transmit to line
OFF - No transmit activity
ON - Data transmitted on line from the module
Rx
Receive from
line
OFF - No receive activity
ON - Data received from the line into the module
FDX
Full Duplex
mode
OFF - Half duplex mode (ports 1 to 24/48)
ON - Full duplex mode (ports 1 to 24/48)
Always ON for ports 51,52 (full-duplex mode
only)
Hspd
High Speed
Ports 1-24/48 Ports 51,52
OFF:
10 Mbps
N/A
ON:
100 Mbps
1000 Mbps
LAG
Link
Aggregation
Group
(Trunking)
OFF - No LAG defined for this port
ON - Port belongs to a LAG
Table 3: C360 Function LED Descriptions 2 of 3
