Specifications
230 Installation and Configuration Guide Avaya C360 Multilayer Stackable Switches, version 4.5
Console Pin Assignments
For direct Console communications, connect the C360 to the Console Terminal using the
supplied RJ-45 crossed cable and RJ-45 to DB-9 adapter.
Tip:
Tip:
Pin 1 of the Modem DB-25 connector is internally connected to Pin 7 GND.
C360 RJ-45 Pin
Name
(DCE View)
Terminal
DB-9 Pins
Modem
DB-25 Pins
1
For future use
NC
See note
2
TXD
(C360 input)
3
3
3
RXD
(C360 output)
2
2
4
CD
4
8
5
GND
5
7
6
DTR
1
20
7
RTS
8
4
8
CTS
7
5
