Page 39: Figure 11
Rack Mounting (Optional)
Issue 1 July 2006
39
Figure 9: C360 Rack Mounting (except C364T NEBS)
Figure 10: C360 Rack Mounting - Front Mount (C364T NEBS only)
Figure 11: C360 Rack Mounting - Mid Mount (C364T NEBS only)
2. Firmly attach the brackets to the chassis with the screws provided.
Figure notes:
1. Front mount position
2. Mid-mount position
1
2
