Juniper Systems TK6000 Cell Modem User Manual
Page 5
Cell Modem Expansion Pack
cAUTiON:
There is space between the case and the
connector. When inserting the card make sure that the
card is inserted into the connector and not into the space
above or below the connector.
4.
Replace the rubber cover. Run a finger around the
outside edge to make sure the gasket is flush with the
case. Note: The top portion of the gasket is not flush.
cAUTiON:
If the rubber cover is not replaced the unit is
no longer sealed and the warranty is void.
5.
Remove the four screws
from the back of the
handheld. Note: They do not
have to be completely
removed from the back.
6.
Remove the back of the
handheld.
7.
Slide the top of the
handstrap up to detach it
from the back.
8.
Place the pack on the back of the handheld.
9.
Tighten the four screws to attach the pack.
10.
Slide the handstrap onto the two screws to reattach it.
!!
!!
