26 IFS MCR205-1T/1S User Manual
Port
TP port and Fiber port.
Link
Displays the current connection speed and duplex mode of TP or Fiber port.
Mode
Allows configuring of the TP or Fiber port speed and operation mode. Use the menu bar to select the
mode.
TP Port:
y Auto Speed Setup Auto negotiation
y 1000 Full Force sets 1000Mbps Full-Duplex mode
y 100 Full Force sets 100Mbps Full-Duplex mode
y 100 Half Force sets 100Mbps Half-Duplex mode
y 10 Full Force sets 10Mbps Full-Duplex mode
y 10 Half Force sets 10Mbps Half-Duplex mode
Default mode: Auto Speed.
Fiber Port:
y Auto Speed Setup Auto negotiation
y 1000 Full Force sets 1000Mbps Full-Duplex mode
Default mode: Auto Speed
Flow Control
Disable or Enable Flow Control of TP or Fiber port.
Enable: IEEE 802.3x Flow Control is enabled on Full-Duplex mode or Backpressure is enabled
on Half-Duplex mode
Disable: No Flow Control or backpressure function on neither Full-Duplex nor Half-Duplex
mode
Default mode: Disable
Ingress Rate Limit The value of inbound traffic limitation in kilobit-per-second (kbps). The available options are :
• No Limit
• 512K
• 1M
• 2M
• 4M
• 8M
• 10M
• 50M
• 100M
• 500M
Default mode: No Limit
Egress Shaping The value of outbound traffic limitation in kilobit-per-second (kbps). The available options are :
• No Limit
• 512K
• 1M
• 2M
• 4M
• 8M
• 10M
• 50M
• 100M
• 500M
Default mode: No Limit
Apply Button
Press this button to save current configuration of MCR205-1T/1S.
Refresh Button
Press “Refresh” button to refresh current status.
