Basic Function Codes - The Modbus packet structure is determined by the function code being
performed. Some of the basic commands that CMS supports are shown in Table 4.
Table 4: Modbus function codes
Function Hex Code
Read Holding Registers 03
Read Input Registers 04
Read Exception Status 07
Write Multiple Registers 10
Write Holding Register 06
Exception Packet Definition - If an error is detected in one of the following packet definitions a
certain error code is applied and sent back in an exception response.
Table 5: Modbus error codes
Code Description
01 Invalid function code – function code not supported by device
02
Invalid data address – address defined by the start address and
number of registers is out of valid range
03 Invalid data value – number of registers = 0 or > 125
Table 6: Modbus exception response
Type Byte Length Example
Device address 1 Byte (1 – 247) 0x01
Function code 1 Byte (Function code + 0x80) 0x83
Exception code 1 Byte 0x01
