IC Realtime Max Series: 4/8/16 Channel D1 1.5U Standalone DVR User Manual
Page 162
152
The tour interface is shown as in Figure 7-75. Here you can set tour interval, split mode, motion
detect tour and alarm tour mode.
Figure 7-75
Please refer to the following sheet for detailed information.
Parameter
Function
Enable tour
Check the box here to enable tour function.
Interval
Here is for you to adjust transparency. The value ranges from 5 to
120s. The default setup is 5s.
Split
Here you can set window mode and channel group. System can
support 1/4/8/9/16/25/36-window according to device channel
amount.
Motion
tour/Alarm
tour
Here you can set motion detect tour/alarm tour window mode.
System supports 1/8-window now.
7.8.5.3.4 Video Matrix
The video matrix interface is shown as in Figure 7-76.
Here you can set video matrix output channel and interval. It supports 1/4/9/16 spot tour.
