IC Realtime Max Series: 4/8/16 Channel D1 1.5U Standalone DVR - Manual (Page 161)

151
7.8.5.3.1 GUI
Here you can set background color and transparency level. See Figure 7-73.
Figure 7-73
Please refer to the following sheet for detailed information.
Parameter Function
Resolution
There are four options: 1280×1024(default),1280Ч720,1024Ч
768,800Ч600. Please note the system needs to reboot to activate
current setup.
Transparency Here is for you to adjust transparency. The value ranges from 128
to 255.
Time
title/channel
title
Check the box here, you can view system time and channel
number on the monitor video.
enhance
Check the box; you can optimize the margin of the preview video.
7.8.5.3.2 TV Adjust
It is to set TV output region. See Figure 7-74.
Figure 7-74
7.8.5.3.3 Tour
