130
Figure 7-34
7.8.2.10 SNMP
The SNMP interface is shown as in Figure 7-35.
The SNMP allows the communication between the network management work station software
and the proxy of the managed device.
Figure 7-35
Please refer to the following sheet for detailed information.
Parameter Function
SNMP Port The listening port of the proxy program of the device. It is a
UDP port not a TCP port. The value ranges from 1 to 65535.
The default value is 161
Read Community It is a string. It is a command between the manage process
and the proxy process. It defined the authentication, access
control and the management relationship between one proxy
and one group of the managers. Please make sure the device
and the proxy are the same.
