sites to help you get started the right way. There are over 2,500
AMA chartered clubs across the country. Contact the AMA at
the address or toll-free phone number below:
1. Your Great Planes Patriot XL should not be considered a
toy, but rather a sophisticated, working model that functions
very much like a full-size airplane. Because of its
performance capabilities, the Great Planes Patriot XL, if not
assembled and operated correctly, could possibly cause
injury to yourself or spectators, and damage to property.
2. You must assemble the model according to the
instructions. Do not alter or modify the model, as doing so
may result in an unsafe or unflyable model. In a few cases
the instructions may differ slightly from the photos. In those
instances the written instructions should be considered
as correct.
3. You must take time to build straight, true and strong.
4. You must use an R/C radio system that is in first-class
condition and a correctly sized engine and components (fuel
tank, wheels, etc.) throughout the building process.
5. You must correctly install all R/C and other components so
that the model operates correctly on the ground and in the air.
6. You must check the operation of the model before every
flight to insure that all equipment is operating and that the
model has remained structurally sound. Be sure to check
clevises or other connectors often and replace them if they
show any signs of wear or fatigue.
7. If you are not an experienced pilot or have not flown this
type of model before, we recommend that you get the
assistance of an experienced pilot in your R/C club for your
first flights. If you’re not a member of a club, your local hobby
shop has information about clubs in your area whose
membership includes experienced pilots.
8. While this kit has been flight tested to exceed normal use,
if the plane will be used for extremely high stress flying,
such as racing, the modeler is responsible for taking steps
to reinforce the high stress points.
Remember: Take your time and follow the instructions to
end up with a well-built model that is straight and true.
Before starting to build, compare the parts in this kit with the
Parts List, and note any missing parts. Also inspect all parts
to make sure they are of acceptable quality. If any parts are
missing, broken or defective, or if you have any questions
about building or flying this airplane, please contact Great
Planes at the address or telephone number below. If
requesting replacement parts, please provide the full kit
name (Great Planes Patriot XL) and the part numbers as
listed in the Parts List.
Great Planes Product Support:
3002 N Apollo Drive Suite 1
Champaign, IL 61822
Telephone: (217) 398-8970, Fax: (217) 398-7721
E-mail: [email protected]
This is a partial list of items required to finish the Patriot XL
that may require planning or decision making before starting
to build. Order numbers are provided in parentheses.
You must use a minimum of a 6-channel radio with two
Y-harnesses, one for the ailerons and one for the elevators.
Due to the fact that the two elevator servos move in
opposition, you will have to have either a computer radio, or
a servo reverser that will allow you to reverse one of the
servos. If using a Futaba
® radio, the SR10 servo reverser
(FUTM4150) is recommended. One standard Y-harness
will also be required for the two aileron servos (HCAM2500).
The Patriot XL may be built either with or without flaps. Flaps
are not necessary for an enjoyable flying experience.
Landing with flaps is a blast (and can be safer) because the
Flaps
Radio Equipment
DECISIONS YOU MUST MAKE
We, as the kit manufacturer, provide you with a top
quality, thoroughly tested kit and instructions, but
ultimately the quality and flyability of your finished model
depends on how you build it; therefore, we cannot in any
way guarantee the performance of your completed
model, and no representations are expressed or implied
as to the performance or safety of your completed model.
PROTECT YOUR MODEL, YOURSELF
& OTHERS...FOLLOW THESE
IMPORTANT SAFETY PRECAUTIONS
IMPORTANT!!!
Two of the most important things you can do to preserve the
radio controlled aircraft hobby are to avoid flying near full-
scale aircraft and avoid flying near or over groups of people.
Academy of Model Aeronautics
5151 East Memorial Drive
Muncie, IN 47302
Tele: (800) 435-9262
Fax (765) 741-0057
Or via the Internet at:
http://www.modelaircraft.org
