2E48-27R/2E49-27R User’s Guide 4-1
CHAPTER 4
TROUBLESHOOTING
This chapter provides information concerning the following:
• Using LANVIEW ( Section 4.1 )
• FE-100TX LED ( Section 4.2 )
• Troubleshooting Checklist ( Section 4.3 )
• Using the RESET Button ( Section 4.4 )
4.1 USING LANVIEW
The 2E4X-27R uses the Cabletron Systems built-in visual diagnostic and
status monitoring system called LANVIEW. The LANVIEW LEDs
(
Figure 4-1 ) allow quick observation of the network status to aid in
diagnosing network problems. Refer to Table 4-1 for a description of the
LEDs.
For a functional description of the LANVIEW LED on the optional Fast
Ethernet Interface Module (FE-100TX), refer to
Section 4.2 .
All LEDs for the High Speed Interface Module (HSIM) are located on the
HSIM and are described in the associated HSIM user’s guide.
Figure 4-1 LANVIEW LEDs
