Using the RESET Button
2E48-27R/2E49-27R User’s Guide 4-7
4.4 USING THE RESET BUTTON
The RESET button shown in Figure 4-3 resets the 2E4X-27R processor
without affecting the NVRAM.
Figure 4-3 RESET Button
To reset the 2E4X-27R processor, press and release the RESET button.
The 2E4X-27R goes through a reset process for approximately 45
seconds. Additional downtime may result as the device reenters the
network.
!
CAUTION
Pressing the RESET button resets the device, and all current
switching being performed by the device is halted. A network
downtime of up to two minutes will result from this action.
TX
TX
TX RX
RX
17
RX
9
RESET Button
2E48-27R
23141-37
PWR
CPU COM
RESET
RX TX
18
RX TX
2
10
RX TX
1
