Port Redirect Function Screen
2E48-27R/2E49-27R User’s Guide 5-61
Figure 5-25 Port Redirect Function Screen
The following definitions briefly explain each field of the Port Redirect
Function screen:
Source Port (Read-only)
Shows which ports are currently set as source ports.
Destination Port (Read-only)
Shows which ports are currently set as destination ports.
Remap Errors (Read-only)
Displays whether the corresponding source ports are configured ON to
send errored frames to the destination ports, or OFF to drop all errored
frames and only forward traffic without errored frames to the destination
ports.
Source Port [ n] (Selectable)
Allows a selected port [n] to be changed to a source port. For details, refer
to
Section 5.17.2 .
Firmware Revision: XX.XX.XX
Port Redirect Function
23142_22
BOOTPROM Revision: XX.XX.XX
Source Port:
1
1
1
2
2
3
3
3
Destination Port:
2
3
4
1
3
4
5
6
Device Type: 2E48-27R
Remap Errors:
ON
ON
ON
OFF
OFF
ON
ON
ON
============ ============ ============
2E48-27R LOCAL MANAGEMENT
Event Message Line
SAVE PREVIOUS
RETURN
RETURN NEXT
Source Port [1] Destination Port [1] Status [ADD]
EXIT
Errors [ON]
