Vehicle Care 10-41
License Plate Lamp
To replace one of these bulbs:
1. Reach under the rear bumper for
the bulb socket.
2. Turn the bulb socket
counterclockwise and pull the
bulb socket out of the connector.
3. Pull the old bulb straight out
from the bulb socket.
4. Push the new bulb straight in
until it clicks to secure it.
5. Reach under the rear bumper to
reinstall the bulb socket into the
connector.
6. Turn the bulb socket clockwise
to secure it to the connector.
Replacement Bulbs
Exterior Lamp
Bulb
Number
Cargo Lamp
and Center
High‐Mounted
Stoplamp (CHMSL)
912LL
License Plate Bulb 168LL
Exterior Lamp
Bulb
Number
Headlamps
High-beam 9005
Low-beam/
Daytime
Running
Lamp (DRL)
9006
Parking/Front Turn
Signal
3757KA
Parking Lamp
(Inboard)
3157A
Stoplamp, Rear
Turn Signal,
Taillamp, and
Back‐up Lamp
3057
For replacement bulbs not listed
here, contact your dealer.
