Black plate (38,1) GMC Canyon Owner Manual - 2011
10-38 Vehicle Care
Headlamps
A. Low-Beam Headlamp/Daytime
Running Lamps (DRL)
B. High-Beam Headlamp
To replace one of these bulbs:
1. Open the hood. See Hood on
page 10‑5.
2. Reach in and access the bulb
sockets from inside the engine
compartment.
3. Turn the bulb socket
counterclockwise to remove it
from the headlamp assembly
and pull it straight out.
4. Unplug the electrical connector
from the old bulb by releasing
the clips on the bulb socket.
5. Pull the old bulb straight out.
6. Push the new bulb straight in
until it clicks to secure it.
7. Plug in the electrical connector
to the new bulb socket.
8. Push the bulb socket straight in
and turn it clockwise to secure it
in the headlamp assembly.
Front Turn Signal,
Parking, and Daytime
Running Lamps (DRL)
To replace one of these bulbs:
1. Open the hood. See Hood on
page 10‑5.
2. Reach in to access either one of
the bulb sockets in the engine
compartment.
