CY7C1302DV25
Document #: 38-05625 Rev. *A Page 10 of 18
Output Times
t
TDOV
TCK Clock LOW to TDO Valid 20 ns
t
TDOX
TCK Clock LOW to TDO Invalid 0 ns
TAP Timing and Test Conditions [12]
Identification Register Definitions
Instruction Field
Value
Description CY7C1302DV25
Revision Number (31:29) 000 Version number.
Cypress Device ID (28:12) 01011010010010110 Defines the type of SRAM.
Cypress JEDEC ID (11:1) 00000110100 Allows unique identification of SRAM vendor.
ID Register Presence (0) 1 Indicate the presence of an ID register.
TAP AC Switching Characteristics Over the Operating Range (continued)
[11, 12]
Parameter Description Min. Max. Unit
(a)
TDO
C
L
= 20 pF
Z
0
= 50
Ω
GND
1.25V
Test Clock
Test Mode Select
TCK
TMS
Test Data-In
TDI
Test Data-Out
TDO
t
TCYC
t
TMSH
t
TL t
TH
t
TMSS
t
TDIS
t
TDIH
t
TDOX
t
TDOV
50
Ω
2.5V
0V
ALL INPUT PULSES
1.25V
