Futaba 12Z User Manual
Page 76
76
Ɣ7ULPPRGH212))VHWWLQJ
1. When changing the trim mode, move the
FXUVRU WR WKH >75,0@ LWHP VHOHFW 212))
by turning the data input dial and set the
selection by pushing the enter button.
*When mixing includes master side trim, select [ON] and
when mixing does not include master trim, select [OFF].
*Effective when a function is set at the master channel.
Ɣ6ODYHFKDQQHO$)5PRGHVHWWLQJ67.67.
0RYHWKHFXUVRUWRWKH>67.67.@LWHPVHOHFW
the mode by turning the data input dial,
and change the mode by pushing the enter
button.
*When link is set at the slave side, and you want to add AFR
(D/R) to the mixing rate, select [ON].
*This is effective when the linkage is the same, but the travels
are substantially different.
Ɣ0L[LQJFXUYHVHWWLQJ
(For a description of the curve setting method, see the
description at the back of this manual.)
Ɣ)LQHWXQLQJWULPVHWWLQJ
Operation control [CTRL], operation mode
[MODE], and rate [RATE] adjustment is possible
by [FINE TUNING] item.
)RUDGHVFULSWLRQRIWKH¿QHWXQLQJWULPVHWWLQJPHWKRGVHH
the description at the back of this manual.)
Ɣ6HUYRVSHHGVHWWLQJLQFOXGLQJRSHUDWLRQVWDUW
point setting)
Adjustment is possible with the [SPEED] item.
(For a description of the servo speed setting method, see the
description at the back of this manual. [Servo Speed Setting
(2)]).
*Offset mixing changes the speed. Use the [Speed] In and
Out buttons to readjust the speed.
*The mixing switch can set a delay [DELAY] with a different
rate at starting and stopping.
*This function is inactive when a mixing switch is not set.
