Receiver nomenclature – Futaba 12Z User Manual
Page 20
20
Receiver R5014DPS
Ɣ
Antenna
Ɣ
Connectors
Ɣ'*
Ɣ0RQLWRU/('
Ɣ&+
Ɣ'*
Ɣ%&
Connector
"1 through 12": outputs for the channels 1 through 12
"DG1", "DG2": outputs of DG1 and DG2 channels
"B/C": connector for the power and DSC.
LED Monitor
This monitor is used when changing the
frequency of the receiver.
Receiver nomenclature
Before using the receiver, be sure to read the precautions listed in the following pages.
