FloAire STAGED ELECTRIC HEAT MODULE - Manual (Page 20)

20
Remote Panel Troubleshooting Chart
Light Indication Condition Possible Cause
No Lights Power not available to Remote Panel Bad voltage to unit
Main disconnect in “OFF” Position
Circuit breaker tripped
Bad main transformer
POWER Light Only Proper unit Off Operation No problem
No power to motor starter Blower On/Blower Off Switch in “Blower
Off” Position
Improper damper function
Low Temperature Thermostat Timed
Out (Option)
POWER Light and
BLOWER ON Light Proper Ventilation Operation No Problem
No Power to Heat Circuit Heat/Vent Switch in “Vent” Position
CLOGGED FILTER Light On
(Optional) Filters Clogged Filters Dirty or Need Replacement
LOW TEMP Light On
(Optional) Freeze-stat has shut blower down Discharge Temperature Too Cold
Heating System is not Functioning
POWER Light and
BLOWER ON Light and
HEAT ON Light Proper Heating Operation No Problem
