FloAire STAGED ELECTRIC HEAT MODULE - Manual (Page 15)

15
Optional Remote Panel Circuit
Power
Supply From
Heater
"Power" Light
On
Off
No Power to
Panel
Panel is
Powered
Blower Switch
Nothing Happens
No Power is Sent
to Heater
Power is Sent to
Heater to Open
Damper (if
provided) and
Start Blower
"Blower Off"
Position
(3-Position Panels Only)
"Blower On"
Position
"Blower On"
Light
Damper is not
Open or Freeze-
Stat has Detected
Low Temperature
Operation
On
Off
Temperature
Control Switch
Blower Operates
Heat Does not
Operate
"Vent"
Position
"Heat"
Position
"Heat On" Light
Turns On
Heat Circuit is
Energized
Blower Operates
Cooling Circuit is
Energized
"Cool"
Position
(if provided)
