6
R Red
B Blue
G Green
AdapTec AC
Access Control/Power Output Module
Siren Tamper
Siren Relay 12V EM Accept Output Switch EXT. Door To Battery
Accept OK 12V MAX 0.5A Voltage Input I/P Exit
0 0 0 12V 0 12V C NC 12V 0 - +
NC2
COM2
NO2
NC1
COM1
NO1
BUT
GND
SEN
485B
485A
GND
232T
232R
GND
WD1
WD0
RJ45-1
RJ45-2
RJ45-3
RJ45-6
BELL+
BELL-
BEEP
GLED
RLED
INWD0
INWD1
GND
+12V
L N E -V +V
Power Supply/Power Input Module
AC110~240V
L - Live
N - Neutral
E - Earth
R B G
WIRING DIAGRAMS
R2/M2, i-Kiosk100, i-Kiosk100 Plus, Q2i and Kadex
TIME ATTENDANCE ONLY
STEP 1 • Connection Points
STEP 2 • Connect AdapTec AC to a Power Source
STEP 3 • Now you can turn on the power source and using the system for
time attendance purpose only.
