background image

3

EC 4-432E 3/95

CONFIGURATION PARAMETERS

CODE PARAMETER

DESCRIPTION

MIN

MAX

U.M.

ST

/0

REGULATOR SELECTION

1=1 absolute and 1 relative setpoint;

0 3

----

2

2=2 absolute setpoint;
3=dead zone.

(1) PA

PASSWORD

-55

+99

----

/

PROBE

/0

kind of probe

30 = 4-20 mA ; 31 = 0-20 mA

30

31

----

30

(1) /1

calibration (measure offset)

-9.0

+10

%rH

0

/2

digital filter (speed response) 0=0s; 1=0.4s; 2=1.2s; 3=3.0s; 4=8.0s; 5=19.8s; 6=48.0s

0

6

----

3

/4

without leading zeros

0=NO; 1=YES

0

1

----

0

/5

with decimal point

0=NO; 1=YES

0

1

----

0

/6

start of scale for input 0-20 mA or 4-20 mA corrispondent to input's minimum value

-99

999

%rH

0

/7

end of scale for input 0-20 mA or 4-20 mA corrispondent to input's maximum value

-99

999

%rH

100

rA/rB

HUMIDITY REGULATOR

rA=refered to setpoint 1; rB=refered to setpoint 2

(1),(2) rA/rB0 regulator hysteresis (differential)

-99

+999

%rH

0

rA/rB1 minimum setpoint admitted

-99

+999

%rH

0

rA/rB2 maximum setpoint admitted

-99

+999

%rH

100

rA/rB3 output action 0=direct (dehumidify); 1=reverse (humidify)

0

1

----

1

rA/rB4 hysteresis selection

0=asymmetric; 1=symmetric

0

1

----

0

rA/rB5 setpoint adjustement locking

0=unlocked; 1=locked

0

1

----

0

CA/CB OUTPUTS ACTIVATION DELAY

CA=refered to output 1; CB=refered to output 2

CA/CB0 output activation delay since instrument power-on

0

999

sec

0

CA/CB1 after start delay

0

999

sec

0

CA/CB2 after stop delay

0

999

sec

0

CA/CB3 relay output status in case of probe failure

0=OFF; 1=ON

0

1

----

0

CA/CB4 ON and OFF delay

0=no delay; 1=3sec

0

1

----

0

AA/Ab ALARM

AA=refered to alarm 1; Ab=refered to alarm 2

AA/Ab0 alarm hysteresis (differential)

1

+99

%rH

0

AA/Ab1 alarm setpoint

-99

+999

%rH

0

AA/Ab3 alarm disabling time since instrument power-on

0

999

min

0

AA/Ab4 alarm mode

see table 1

1

L

NETWORK CONNECTION

L1

instrument address

1

15

----

1

L2

instrument group

0

7

----

0

notes

(1) = configuration parameter on LEVEL 1

(2) = represents dead zone value if parameter –/0=3.

TABLE 1

parameter AA/Ab4 alarm mode

1

disabled

2

absolute minimum alarm

3

absolute maximum alarm

4

minimum alarm relative to setpoint 1

5

maximum alarm relative to setpoint1

6

minimum alarm relative to setpoint 1
with automatic enabling and recompute

7

maximum allarm relative to setpoint 1
with automatic enabling and recompute
