If the LED L2 is turned ON it means that the display of the temperature read by the probe 2 is

running.
If the LED L3 is turned ON it means that the automatic modality is selected.

ALARMS
If the instrument displays the indication E2 flashing (corrupted memory data alarm) it means

that there is a corruption of the configuration data in the memory (turn OFF and turn ON again

the instrument: if to the turning ON again the alarm does not disappear the instrument must be

replaced); during this alarm the selection of the modality with which to display the tempera-

tures read by the probes is refused.
If the instrument displays the indication E0 flashing (probe 1 failure alarm) it means that:

the kind of connected probe 1 is not proper (verify the kind of connected probe 1), the probe 1

is faulty (verify the probe 1 integrity), there is a mistake in the instrument-probe 1 connection

(verify the instrument-probe 1 connection integrity), the temperature read by the probe 1 is

outside the limits permitted by the probe 1 in use (verify that the temperature near the probe 1

be inside the limits permitted by the probe 1); inactive.
If the instrument displays the indication E1 flashing (probe 2 failure alarm) it means that

there is one of the faults saw in the previous case but referred to the probe 2; inactive.
ADDITIONAL INFORMATIONS
-

the alarm codes are related in order of precedence

a probe 1 failure alarm gets displayed during the display of the temperature read by

the probe 1

a probe 2 failure alarm gets displayed during the display of the temperature read by

the probe 2.

TECHNICAL DA

TECHNICAL DAT

TECHNICAL DATA
Case:

plastic black (PC-ABS), self-extinguishing.

Size:

74 x 32 x 65 mm (2.91 x 1.25 x 2.55 in.).

Installation:

panel mounting, panel cutout 71 x 29 mm (2.79 x 1.14 in.),

with the equipped screw or spring brackets.

Type of protection:

IP 54.

Connections:

screw terminal block with pitch 5 mm (0.19 in., power sup-

ply and measure inputs) for cables up to 2.5 mm²

(0.38 in.²), five poles single line male connector with pitch

5.08 mm (0.2 in., serial port).

Ambient temperature:

from 0 to +60

C (+32 to +140

F, 10 ... 90 % of not con-

densing relative humidity).

Power supply:

12 Vac/dc or 12-24 Vac/dc, 50/60 Hz, 1.5 VA.

Insulation class:

II.

Measure inputs:

2 for PTC probes.

Working range:

from -50 to +150

C (-58 to +302

F).

Resolution:

C (1

F).

Display:

3-digit display 12.5 mm (0.49 in.) high red LED display

with automatic minus sign, functioning status indicators,

programming status indicator.

Serial port:

TTL with EVCOBUS protocol communication, for the con-

nection to the CLONE configurer/cloner and RICS supervi-

sion systems.

HOW TO ORDER

CODING SYSTEM
Instrument name:

EC 3-162.

Desired measure input:

P (for PTC probes).

Desired power supply:

012 (12 Vac/dc)

024 (12-24 Vac/dc).

Options:

other values of the frequency with which to display the

temperatures read by the probes during the automatic

modality, presetting to accept at the measure inputs NTC

or Pt 1000 probes, temperature display in

F, green LED

display.
