"Status 3" (dedicated parameters t 0, t 2, t 5, t 6, t 8, t12, t20, t21, t25, t33):
The "Status 3" permits to delay the activation of the following status.
During this status the instrument counts the time established with the parameter "t20", according to the time base established with the parameter
"t 0".
For all the length of this status on the display appear:
- the indication "00:00" if the parameters "t 6" and "t33" have value 0
- the time counted in the preceding status if the parameter "t 6" has value 1 and the parameter "t33" has value 0
- the countdown of the time to be counted in this status if the parameter "t 6" has value 0 and the parameter "t33" has value 1
- the count up of the time to be counted in this status if the parameters "t 6" and "t33" have value 1
the lighting indicators located in the middle of the display alternately flash, the outputs are not activated.
At the end of the established time the "Status 3" ends and the device automatically moves to the "Status 4".
NOTES:
- one "Stop" input during this status forces the instrument to the "Status 0", on the display remains the indication showed during
the "Status 0".
"Status 4" (dedicated parameters t 2, t 3, t 5, t 6, t 7, t 8, t12, t21, t22, t23, t24, t25, t34):
During this status the instrument counts the time established with the parameter "t24", according to the time base established with the parameter
"t23".
For all the length of this status the signalling buzzer is activated according to the modality established with the parameter "t 3", on the display
appear:
- the indication "00:00" if the parameters "t 6" and "t34" have value 0
- the time counted during the "Status 2" if the parameter "t 6" has value 1 and the parameter "t34" has value 0
- the countdown of the time to be counted in this status if the parameter "t 6" has value 0, the parameter "t34" has value 1 and the
parameter "t22" has value 2
- the count up of the time to be counted in this status if the parameters "t 6" and "t33" have value 1 and the parameter "t22" has
value 2
the lighting indicators located in the middle of the display flash at the same time, the output 2 is activated.
At the end of this status:
- if the parameter "t 7" has value 0, the instrument automatically moves to the "Status 0", on the display remains the indication showed
during the "Status 0" (the modality that ends the "Status 4" can be established with the parameter "t22")
- if the parameter "t 7" has value 1 and the parameter "t22" has value 2, the instrument automatically moves to the "Status 1" and
it continues the count.
NOTES: - if the parameter "t21" has value 1, the output 2 always is activated except during this status
- if the parameter "t25" has value 1, the output 2 gets activated/deactivated with the same modality of the output 1, respecting the
parameter "t21" only
- one "Stop" input during this status forces the instrument to the "Status 0", on the display remains the indication showed during
the "Status 0".
"Count holding" function (dedicated parameter t 8):
"Count holding" function was studied to permit to interrupt and to take again a count on run.
Function depends from the parameter "t 8" as indicated:
- if the parameter "t 8" has value 0 the function is inactive
- if the parameter "t 8" has value 1 the function can be activated/deactivated through a "Start" input; for all the length of the "count
holding" on the display flashes the indication showed at the moment of the function activation
- if the parameter "t 8" has value 2 the function is active during the activation of the "E 1" remote input only.
