PREPARATIONS
1.1 How to install the instrument
Panel mounting, panel cut out 92 x 92 mm (3.62 x 3.62 in), with
screw brackets (they are supplied by the builder).
smart guide
PM
100A
Printing module
Version 2.01 of December the fifth, 2002
File pr100ae_v2.01.pdf
PT
EVERY CONTROL S.r.l.
This Company belongs to
Via Mezzaterra 6, 32036 Sedico Belluno ITALY
Phone 0039-0437-852468 • Fax 0039-0437-83648
[email protected] • www.everycontrol.it
installation with screw brackets (position the brackets as indicated); you have to moder-
ate the clamping torque, in order not to damage the box and screw brackets.
2
OPERATION
2.1 How to turn the instrument ON/OFF
If you have to turn the instrument ON/OFF:
• press
2.2 How to feed the paper by hand
If you have to feed the paper by hand:
• press
2.3 How to change the roll of paper
If you have to change the roll of paper:
• turn the instrument OFF
• press
for opening the panel at
the front of the instrument
• slip the roll of paper into the lower side of the roller
• press
as long as the roller drags
the roll of paper
• put the roll of paper into its box
• close the panel at the front of the instrument.
