EVCO EK342AJ7 User Manual
Page 4
Resolution: 1 °F with unit of measure in Fahrenheit, 1 °C with unit of measure in
Celsius.
Display: one red LED 3-digit displays 13.2 mm (0.51 in) high, one red LED 2-digit
display 13.2 mm (0.51 in) high, two LED bars (10 red LED), output status indicators,
indicators of the unit of measure of the temperature showed by the instrument.
Outputs: 3 relays: one 8 A @ 250 Vac relay for top heating group control (NO),
one 8 A @ 250 Vac relay for floor heating group control (NO), one 8 A @ 250 Vac relay
for chamber light control (NO); the maximum current allowed on terminal 26 is 10 A.
10
WORKING SETPOINT AND CONFIGURATION PARAMETERS
10.1 Working setpoint
LABEL MIN. MAX. U.M.
DEF. WORKING SETPOINT
rA1
rA2
°C/°F
(6)
0
working setpoint
10.2 First level parameters
LABEL MIN. MAX. U.M.
DEF. PASSWORD
PA
-90
100
---
0
password
LABEL MIN. MAX. U.M.
DEF. MEASURE INPUTS
/1
-10
10
°C/°F
(6)
0
chamber probe calibration
LABEL MIN. MAX. U.M.
DEF. REGULATOR
rA0
-15
-1
°C/°F
(6)
-2
hysteresis (differential, it is relative to the working setpoint)
10.3 Second level parameters
LABEL MIN. MAX. U.M.
DEF. MEASURE INPUTS
/0
10
11
---
10
kind of probe (10 = “J” Tc, 11 = “K” Tc)
/1
-10
10
°C/°F
(6)
0
chamber probe calibration
/2
0
6
---
3
probe reading speed (0 = fast, ... , 6 = slow)
/4
0
1
---
0
display of non meaningful zeros (1 = YES)
/8
0
1
---
1
unit of measure temperature (0 = Fahrenheit degree, 1 = Celsius degree)
LABEL MIN. MAX. U.M.
DEF. REGULATOR
rA0
-15
-1
°C/°F
(6)
-2
hysteresis (differential, it is relative to the working setpoint)
rA1
0
rA2
°C/°F
(6)
0
minimum value you can assign to the working setpoint
rA2
rA1
999
°C/°F
(6)
300
maximum value you can assign to the working setpoint
LABEL MIN. MAX. U.M.
DEF. FIRST ALARM
AA0
1
99
°C/°F
(6)
2
hysteresis (differential, it is relative to AA1, it is important if AA4 ≠ 1)
AA1
-99
999
°C/°F
(6)
0
first temperature alarm threshold (it is important if AA4 ≠ 1); look at AA4 as well
AA3
0
999
min
0
first temperature alarm exclusion time since you turn the instrument ON (it is important if
AA4 ≠ 1)
AA4
1
7
---
1
kind of temperature alarm (1 = it will never be activated, 2 = absolute lower temperature
alarm, 3 = absolute upper temperature alarm, 4 = lower temperature alarm relative to the
working setpoint, 5 = upper temperature alarm relative to the working setpoint,
6 = lower temperature alarm relative to the working setpoint with automatic calculation and
enabling, 7 = upper temperature alarm relative to the working setpoint with automatic
calculation and enabling)
