MRK+Line Reference Manual
www.digilentinc.com
page 2 of 11
Copyright Digilent, Inc. All rights reserved. Other product and company names mentioned may be trademarks of their respective owners.
The following tools are recommended for robot assembly:
•
regular and small Phillips head screwdrivers
•
adjustable wrench
•
pliers
•
wire stripper
Example Assembly
1. Place the motor mount on the right side of the platform. Attach it with two screws.
2. Attach the motors to the motor mount with the miniature screws.
