Universal Development Board™ Reference Manual
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
Page 20 of 27
69 17 J10-1, RA0 RA0/TMS
70 38 J10-6, RA1 RA1/TCK
71 60 J10-3, RA4 RA4/TDI
72 61 J10-8, RA5 RA5/TDO
73 91 J10-5, RA6 RA6
74 92 J10-10, RA7 RA7
75 26 J10-7, RB6 RB6/AN6
76 27 J10-12, RB7 RB7/AN7
77 20 J10-9, RB5 RB5/AN5
78 13 J10-14, MCLR MCLR
79 34 J10-11, RB10 RB10/PMPA13
80 35 J10-16, RB11 RB11/PMPA12
81 41 J10-13, RB12 RB12/PMPA11
82 42 J10-18, RB13 RB13/PMPA10
83 43 J10-15, RB14 RB14/PMPA1 JA-10
84 44 J10-20, RB15 RB15/PMPA0 JA-7
85 6 J10-17, RC1 RC1
86 7 J10-22, RC2 RC2
87 8 J10-19, RC3 RC3
88 9 J10-24, RC4 RC4
89 73 J10-21, RC13 RC13
90 74 J10-26, RC14 RC14
91 N/C
92 N/C
93 72 J10-25, RD0 RD0
94 76 J10-28, RD1 RD1
95 77 J10-27, RD2 RD2
96 78 J10-30, RD3 RD3/PMPBE
97 81 J10-29, RD4 RD4/PMPWR JA-9
98 82 J10-32, RD5 RD5/PMPRD JA-8
99 83 J10-31, RD6 RD6
100 84 J10-34, RD7 RD7
101 68 J10-33, RD8 RD8
102 69 J10-36, RD9 RD9
103 70 J10-35, RD10 RD10/PMPCS2
104 71 J10-38, RD11 RD11/PMPCS1
105 79 J10-37, RD12 RD12
