32 N/C
33 14 J9-21, RG9 RG9/PMPA2/SS2 SPI2 SS, JA-1
34 49 J9-24, RF4 RF4/PMPA9/U2RX UART2 RXD
35 10 J9-23, RG6 RG6/PMPA5/SCK2 SPI2 SCK, JA-4
36 50 J9-22, RF5 RF5/PMPA8/U2TX UART2 TXD
37 11 J9-25, RG7 RG7/PMPA4/SDI2 JA-3
38 58 J9-26, RA2 RA2/SCL2
39 12 J9-27, RG8 RG8/PMPA3/SDO2 JA-2
40 59 J9-28, RA3 RA3/SDA2
41 GND
42 GND
43 32 J9-29, RB8 RB8/AN8
44 33 J9-30, RB9 RB9/AN9
45 28 J9-31, RA9 RA9/PMPA7
46 29 J9-32, RA10 RA10/PMPA6
47 GND
48 GND
49 67 J9-33, RA15 RA15/INT4
50 66 J9-34, RA14 RA14/INT3
51 40 J9-35, RF12 RF12/U2CTS
52 39 J9-36, RF13 RF13/U2RTS
53 VCC3V3
54 VCC3V3
55 VCC5V0
56 VCC5V0
57 VCC9V0
58 VCC9V0
59 N/C
60 90 J9-38, RG0 RG0
61 N/C
62 89 J9-40, RG1 RG1
63 N/C
64 N/C
65 1 J9-37, RG15 RG15
66 97 J10-2, RG13 RG13
67 96 J9-39, RG12 RG12
68 95 J10-4, RG14 RG14
