Pinout Table by PIC32 Microcontroller Pin
MCU
Pin
Port
Bit
ChipKIT
Pin #
PIC32 Signal Name
Function
1
RG15
49
AERXERR/RG15
SD Card
2
N/A
VDD
POWER
3
RE05
31
PMD5/RE5
GPIO
4
RE06
32
PMD6/RE6
GPIO
5
RE07
33
PMD7/RE7
GPIO
6
RC01
67
T2CK/RC1
(shared with digital
pin 34)
7
RC02
68
T3CK/RC2
(shared with digital
pin 35)
8
RC03
69
T4CK/RC3
(shared with digital
pin 36)
9
RC04
38
T5CK/SDI1/RC4
GPIO
10
RG06
13
ECOL/SCK2/U6TX/U3RTS/PMA5/CN8/RG6
SPI_SCK, User LED
LD6
11
RG07
12
ECRS/SDA4/SDI2/U3RX/PMA4/CN9/RG7
SPI_SDI
12
RG08
11
ERXDV/AERXDV/ECRSDV/AECRSDV/SCL4/SDO2/U3TX/PMA3/CN10/RG8
SPI_SDO
13
N/A
MCLR
ICSP
14
RG09
44
ERXCLK/AERXCLK/EREFCLK/AEREFCLK/SS2/U6RX/U3CTS/PMA2/CN11/RG9
SPI_SS (JPR to
digital pin 10
position)
15
N/A
VSS
POWER
16
N/A
VDD
POWER
17
RA00
47
TMS/RA0
User LED LD3
