Pinout table by mcu port and bit – Digilent 410-273P-KIT User Manual
Page 17
WF32 Reference Manual
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
Page 17 of 24
N/A
46
VDD
POWER
N/A
54
VBUS
POWER
N/A
55
VUSB
POWER
N/A
62
VDD
POWER
N/A
65
VSS
POWER
N/A
75
VSS
POWER
N/A
85
VCAP/VDDCORE
POWER
N/A
86
VDD
POWER
Pinout Table by MCU Port and Bit
Port
Bit
MCU
Pin
ChipKIT
Pin #
PIC32 Signal Name
Function
RA00
17
47
TMS/RA0
User LED LD3
RA01
38
48
TCK/RA1
User LED LD4
RA02
58
45
SCL2/RA2
I2C, wire (jumper
to A5)
RA03
59
46
SDA2/RA3
I2C, wire (jumper
to A4)
RA04
60
62
TDI/RA4
I2C Pullup (SDA)
RA05
61
63
TDO/RA5
I2C Pullup (SCL)
RA06
91
65
TRCLK/RA6
BTN1
RA07
92
66
TRD3/RA7
BTN2
RA09
28
41
Vref-/CVref-/AERXD2/PMA7/RA9
GPIO, VREF-
RA10
29
42
Vref+/CVref+/AERXD3/PMA6/RA10
VREF+
RA14
66
8
AETXCLK/SCL1/INT3/RA14
GPIO, external INT
(shared with
P32_USBOC)
RA15
67
57
AETXEN/SDA1/INT4/RA15
MRF24 INT
RB00
25
17/A3
PGED1/AN0/CN2/RB0
AIN3, GPIO
RB01
24
23/A9
PGEC1/AN1/CN3/RB1
AIN9, GPIO
RB02
23
14/A0
AN2/C2IN-/CN4/RB2
AIN0, GPIO
RB03
22
20/A6
AN3/C2IN+/CN5/RB3
AIN6, GPIO
RB04
21
15/A1
AN4/C1IN-/CN6/RB4
AIN1, GPIO
RB05
20
21/A7
AN5/C1IN+/VBUSON/CN7/RB5
AIN7,
P32_VBUSON
RB06
26
N/A
PGEC2/AN6/OCFA/RB6
ICSP
RB07
27
N/A
PGED2/AN7/RB7
ICSP
RB08
32
16/A2
AN8/C1OUT/RB8
AIN2, GPIO
