WF32 Reference Manual
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
Page 19 of 24
RE01
94
27
PMD1/RE1
GPIO
RE02
98
28
PMD2/RE2
GPIO
RE03
99
29
PMD3/RE3
GPIO
RE04
100
30
PMD4/RE4
GPIO
RE05
3
31
PMD5/RE5
GPIO
RE06
4
32
PMD6/RE6
GPIO
RE07
5
33
PMD7/RE7
GPIO
RE08
18
2
AERXD0/INT1/RE8
GPIO, external INT
RE09
19
7
AERXD1/INT2/RE9
GPIO, external INT,
USBOC INT
RF00
87
43
ETXD1/PMD11/RF0
User LED LD5
RF01
88
4
ETXD0/PMD10/RF1
GPIO
RF02
52
0
SDA3/SDI3/U1RX/RF2
GPIO, UART
RF03
51
N/A
USBID/RF3
P32_USBID
RF04
49
55
SDA5/SDI4/U2RX/PMA9/CN17/RF4
MRF24 SPI
RF05
50
56
SCL5/SDO4/U2TX/PMA8/CN18/RF5
MRF24 SPI
RF08
53
1
SCL3/SDO3/U1TX/RF8
GPIO, UART
RF12
40
54
SS4/U5RX/U2CTS/RF12
MRF24 SPI
RF13
39
53
SCK4/U5TX/U2RTS/RF13
MRF24 SPI
RG00
90
59
PMD8/RG0
MRF24 RESET
RG01
89
58
ETXERR/PMD9/RG1
MRF24 HIBERNATE
RG02
57
N/A
D+/RG2
P32_USBD+
RG03
56
N/A
D-/RG3
P32_USBD-
RG06
10
13
ECOL/SCK2/U6TX/U3RTS/PMA5/CN8/RG6
SPI_SCK, User LED
LD6
RG07
11
12
ECRS/SDA4/SDI2/U3RX/PMA4/CN9/RG7
SPI_SDI
RG08
12
11
ERXDV/AERXDV/ECRSDV/AECRSDV/SCL4/SDO2/U3TX/PMA3/CN10/RG8
SPI_SDO
RG09
14
44
ERXCLK/AERXCLK/EREFCLK/AEREFCLK/SS2/U6RX/U3CTS/PMA2/CN11/RG9
SPI_SS (JPR to
digital pin 10
position)
RG12
96
51
TRD1/RG12
SD Card
RG13
97
52
TRD0/RG13
SD Card
RG14
95
50
TRD2/RG14
SD Card
RG15
1
49
AERXERR/RG15
SD Card
2
N/A
VDD
POWER
13
N/A
MCLR
ICSP
15
N/A
VSS
POWER
16
N/A
VDD
POWER
30
N/A
AVDD
POWER
