ConvertiBARS Yamaha: FZ1(00-05) - Manual

Yamaha FZ1(00-05)
Bike Specific Install Notes and Tips
This is an aftermarket product that fits up different than the stock components, therefore, the installer may be required to
set up components and to route lines in the ?best way possible?, which may not always be listed on this ?Bike
Specific? installation sheet. In any case, the installation must allow the handlebars to reach both steering stops, with
out pulling taught or kinking any lines, and without damaging any part of the motorcycle
Important Installation Considerations
6.5 inch tall handlebars do not require longer lines.
Restrictions
1. Foreword Positions restricted by instrument panel
2. Fairing side pieces or intake ducts interfere with the riser when rotating the
Cyclops Clamps. Raising the handlebar so the riser is above the fairing side
pieces before rotating the Cyclops clamps will solve this restriction. Trimming
the fairing side pieces could also increase convertibility.
Recommended Riser Trim Length
1. 6.5" Riser Length = Trim Number 11
Recommended parts and replacement lines
1. Longer lines than stated here may be required if raising the bars more than the
recommended trim length.
2. Hydraulic Clutch Line Top Fitting - 90 degree face to the side
