Kawasaki ZX-6RR+636(03-04)

Bike Specific Install Notes and Tips

This is an aftermarket product that fits up different than the stock components, therefore, the installer may be required to

set up components and to route lines in the ?best way possible?, which may not always be listed on this ?Bike

Specific? installation sheet. In any case, the installation must allow the handlebars to reach both steering stops, with

out pulling taught or kinking any lines, and without damaging any part of the motorcycle

Important Installation Considerations


Special Kit Requirements/Installation Tips

1. Contact - Slight fairing contact is ok as long as the steering stops can be

reached with out damaging the fairing


Restrictions

1. Upper fairing and or windshield can be trimmed for more rise.


Line Routing

1. Electrical Lines to be freed from their brackets and or Zip Ties, and run on the

rider's side of the forks


Recommended Riser Trim Length

1. 6.5" Riser Length = Trim Number 11


Recommended parts and replacement lines

1. Kawasaki 6RR/636 (03-04) Stock+75mm Throttle Lines (part number X-620.

Order from ConvertiBARS

2. Hydraulic Brake Line Top Fitting - 90 degree face to the side

3. Hydraulic Brake Line = Stock + 5"

4. Throttle Lines - Stock + 2"
