ConvertiBARS Honda: VFR-800(.98-99) - Manual

Honda VFR-800(.98-99)
Bike Specific Install Notes and Tips
This is an aftermarket product that fits up different than the stock components, therefore, the installer may be required to
set up components and to route lines in the ?best way possible?, which may not always be listed on this ?Bike
Specific? installation sheet. In any case, the installation must allow the handlebars to reach both steering stops, with
out pulling taught or kinking any lines, and without damaging any part of the motorcycle
Important Installation Considerations
Special dual brake line works with linked braking system. Remove the top line(2
lines with a junction block)and the hard cross over line. The replacement lines
Both bolt at the master cylinder using a double banjo bolt and 3 washers. On
the opposite ends, the line with the male threaded end, attaches to the clutch
side crossover block. The second line attaches directly to the right caliper.
Special Kit Requirements/Installation Tips
1. Contact - Slight fairing contact is ok as long as the steering stops can be
reached with out damaging the fairing
2. Trimming - Depending on rise and preference, trimming the handlebar length
will allow more rise
3. Moving - Moving the clutch lever, and brake lever toward the center of the
motorcycle will allow greater upper fairing/windshield clearance
Restrictions
1. Triple Clamp Pinch Bolts restrict forword and or aft positioing if using the 8mm
web clamps(ex. 41-875-08). 41mm and 43mm clamps are also offered with a
26mm web distance which locates the riser pipe further outboard avoiding the
pinch bolts.
Recommended Riser Trim Length
1. 5.0" Riser Length = Trim Number 8
Recommended parts and replacement lines
1. Honda VFR-800(98-99) Stock+75mm length Throttle Lines(Part Numbers, 07-
0805, 07-0807. Order from ConvertiBARS
2. Hydraulic Brake Line Top Fitting - 90 degree face to the side
3. Hydraulic Brake Line = Stock + 3"
4. Hydraulic Clutch Line Top Fitting - 90 degree face to the side
5. Hydraulic Clutch Line = Stock + 2"
