To Adjust Recline on Base:
To raise recline on base: Pull handle out
and push down as shown to one of the
3 positions
O.
To lower recline on base: pull handle out and up
until it is in the desired position ©.
There are 3 recline options.
You can identify them by the
numbers 1 through 3 in the
window on the front of the foot.
If there is red in the level indicator when the foot
is completely extended place a rolled towel
under the foot © until ONLY GREEN shows.
To Adjust Recline on Infant Restraint
WITHOUT Base:
When using only the infant restraint, CHECK
infant restraint is level with the ground. Red
level line on the warning label (see step © on
pg 35) MUST be level with the ground.
If the infant restraint is resting on the vehicle seat
and is still not level then place a rolled towel under
the infant restraint O.
Readjust the vehicle seat belt as necessary
to secure the infant restraint firmly in the
vehicle seat.
