Installing Yout Refrigerator

How to Connect the Water Supply

WARNING

To avoid electrical shock which cao cause severe personal Injury or death, disconnect power to refrigerator before
connecting water supply- After connecting water supply, connect power.

A CAUTION

To avoid property damage, observe the following;

■ Consult a plumber to connect copper tubing to household plumbing to assure compliance with local codes and

ordinances

■ Confirm water pressure to water valve is between 20 and 100 pounds per square inch If water Ritsr is installed, water

pressure to water valve must be a minimum of 35 pounds per square inch.

■ DO NOT use a self^piercing, or ’i,/ {4 8 mm) saddle valve. Both reduce water flow, become clogged with time, and may

cause teaks if repair is attempted

• Tighten nuts by hand to prevent cross threading Finish tighterring nuts with pliers and wrenches Do not overtighten.
' Wait 24 hours before placing unit into final position to check and correct any water leaks

Materials Needed

(6 mm) outer diameter flexible

copper tubing

• Brass nut and sleeve (see

literature pack)

• Shut-off valve (requires a or 6

mm hole to be drilled into water
supply before valve attachment)

• Adjustable wrench

1

Create service loop with mbing using care to

SYOid kinks in tubing.

NOTE: Add 8' (2 m) to tubing length needed to reach

water supply for creation of service loop.

M emore plastic cap

£гош

water valve inlet

port

J

Place brass nut and sleeve on capper tube

>r—.

end

as

illustrated,

A Place end of copper mbing into water valve inlet

»

port. Shape tubing slightly— DO NOT KJNK-so

that tabiag Beds straight into inlet port

Slide brass nut over sl&ve and screw nut into inlet

port Tigbtm nut with wrench. Pull on mbing to

conErm connection Is secure.

IMPORTANT: DO NOT overtighten Cross threading may occur.

Locate water tubing damp and install with !4" hex

head screw, as illustrated. Turn on water supply

and correct any leaks, if

present

7

M onitor water connection Sjr 24 bouts. Correct leaks, if

necessary.
