GE JGBP27DEMWW - Manual (Page 29)

GEAppliances.com
Burner cap is
properly seated.
Burner cap is
NOT properly
seated.
Burner heads (on some models)
The burner heads (on some models)
are removable. Simply lift them off
the range for cleaning.
Tri-ring head (on some models)
Burner head
Electrode
Burner base
Make sure the ring in the burner head
is positioned over the electrode and
that the burner head is fully inserted
inside the burner base. A small gap
between the base and head is normal.
Front-right head (on some models),
front-left head, back-right head and
back-left head
Burner head
Stability chamber
Burner
bas'
Use a sewing
needle or twist-tie
to unclog the
small hole In the
Electrode burner head.
Make sure the slot in the burner head
is positioned over the electrode.
Hole in
burner
head
The oval burner head/cap assembly is
removable. Simply lift it off the range for
cleaning. Use a sewing needle or twist-tie
to unclog the small hole in the burner
heads.
Burner Caps, Bases and Heads
Before removing the burner cops and heads
(on some models), remember their size and
location. Replace them in the same location
after cleaning.
NOTE: Do not use steel wool or scouring
powders to clean the burner parts.
Burner caps
Lift off when cool. Wash burner caps in hot,
soapy water and rinse with clean water. You
may scour with a plastic scouring pad to
remove burned-on food particles.
Tri-ring burner
(on som e m odels)
The outer cap on the trI-rIng burner Is not
rem ovable. Only the center round cap m ay be
rem oved for cleaning.
To clean the burner bases, use soapy water and a
plastic scouring pad. Wipe clean with a damp cloth.
Make sure that no water gets into the burner
bases. Allow them to dry fully before using.
Burner Heads
(on som e m odels)
and Oval
(Center) Burner Head/Cap Assembly
The burner heads and the oval burner head/cap
assem bly are rem ovable. Sim ply lift them off the
range for cleaning.
For proper ignition, make sure the small hole in
the section that fits over the electrode is kept
open. A sewing needle or wire twist-tie works
well to unclog it.
The silts In the burner heads m ust be kept clean
at all tim es for an even, unham pered flam e.
Clogged or dirty burner ports or electrodes will
not allow the burner to operate properly.
Any spill on or around an electrode must
be carefully cleaned. Take care to not hit an
electrode with anything hard or it could be
damaged.
Clean the burner heads routinely, especially
after bad spillovers, which could clog the
openings. Lift off when cool.
To remove burned-on food, soak the burner
heads in a solution of mild liquid detergent
and hot water for 20-30 minutes. For more
stubborn stains, use a toothbrush.
After cleaning
Before putting the burner caps, heads (on some
models) and oval head/cap assembly back,
shake out excess water and then dry them
thoroughly by setting in a warm oven for 30
minutes.
Replacement Burner Heads
(on som e m odels)
Replace burner heads over the electrodes on
the cooktop, in the correct locations according
to their size. There is one small, one medium,
one large and one extra-large burner head.
Make sure the slot or hole (depending on model) in
the burner head is positioned over the electrode.
Electrode
Oval (Center) Burner Head/Cap Assembly
Replace the oval (center) head/cap assembly over
the electrode on the cooktop.
Oval head and cap Make sure the slot In the
Caps
Replace the matching size caps onto the burner
bases or heads.
Make sure that the heads (on some models) and
caps are replaced in the correct locations.
Front of range
(on some models)
TrI-rIng cap
O
(on some models)
29
