22
RECEIVER AND BATTERY INSTALLATION
1. Insert the Y-harness into the the aileron
plug in the receiver and then wrap both the
receiver and the battery in the 1/2" foam.
2. The switch can be mounted in the fuselage
side opposite the exhaust.
You can remove the tank and place the bat-
tery under the tank or it can be placed just in
front of the servo tray depending on where
you need it for balance. If the battery is
under the tank the receiver can go just in
front of the servo tray. If the battery is in front
of the servo tray you can mount the receiver
behind the servo tray under the pushrods.
Move the battery and receiver to achieve the
proper balance.
WING AND STRUT MOUNTING
1. Collect the following items:
(2) Wing Struts
(4) 3mm x 12mm socket head screws
(2) 4mm x 25mm socket head screws
(2) 4mm flat washers
2. Fit the wing into the saddle with the tongue
on the bottom of the bottom of the wing fit-
ting into the notch at the leading edge.
