Carl Goldberg GBGA1092 - Manual (Page 20)

20
7. Using a long 3/16” drill, drill a hole in the fire-
wall in line with the throttle arm on the
engine.
Attach the other 2mm x 30cm pushrod to the
engine throttle arm with a clevis and silicone
keeper. Install the nylon tube on the
pushrod.
8. Attach the pushrod to the servo connector
on the throttle servo and adjust properly.
9. Both the throttle pushrod and the nose gear
steering pushrod will need to be notched
into the bulkhead where the tank fits.
TANK AND HATCH INSTALLATION
1. Install the tank through the wing opening,
through the hole in the bulkhead, and the
cap into the hole in the firewall. Foam (not
included) can be used to cushion the tank
on the sides. Connect the fuel lines from the
fuel pickup to the carburetor, and the vent
line to the muffler.
