10
8. Use the nylon swing in keeper to secure the
pushrod to the control horn.
9. Repeat for the other flap and ailerons.
WING JOINING
1. Locate the dihedral brace and identify the
top and bottom.
bottom
2. Trial fit the dihedral brace in each wing half
and then slide the two wing halves together.
3. When satisfied with the fit, take the wing
apart and mix enough epoxy glue to cover
both wing roots, the dihedral brace and and
the slots in the wing that dihedral brace fit
into. Use a scrap piece of wood to work glue
down into the slots in both wing halves.
Make sure to get glue on both halves of the
tongue on the bottom side that locates the
wing. Use clamps to make sure they are
together firmly.
4. Use masking tape to hold the wing together
till the epoxy sets. Be sure to lay the wing
flat, don’t stand it on one tip or all the glue
will run to one side of the wing.
wing locating tongue
