1. Fuselage
2. Cowl
3. Fin
4. Rudder
5. I-Strut (2)
6. Landing gear legs (2)
7. Wheel Pants (2)
8. Canopy
9. Belly pan
10. Stab
11. Elevators (left and right)
12. Top wing with ailerons
13. Bottom wing with ailerons.
PARTS LIST HARDWARE LIST
Cabane Struts (4) pcs.
(12) 4-40x1/2” socket head screws
(4) #4 flat washers
I Struts (2) pcs.
(8) 4-40x1/2” socket head screws
(8) #4 Flat washers
(8) 4-40 aircraft lock nuts
(8) 1/4”x20 eye bolts
Landing gear 2pcs
(6) 6-32x3/4” socket head screws
(6) #6 Flat washers
(2) 4mm axles with lock nuts
(2) 4mm wheel collars with set screws
(2) 2-3/4” wheels
(2) 4-40 T-nuts
(2) 4-40x1/2” socket head screws.
