Programming a 5-2 Day Schedule
The 5-2 day programming mode allows you to program Monday - Friday
with one 4 event schedule and then allows you to change Saturday and
Sunday with a different 4 event schedule.
1. Press the
PROG button. The display will switch
to programming mode. The days M, TU, W, TH,
and F will be displayed and the hour will
be flashing.
2. Move the
SYSTEM switch to either the HEAT
or COOL position.
3. Press the or to adjust the hour for the MORN (morning) event.
Press
PROG.
4. Press or to adjust the minute for the MORN event. Press PROG.
5. Press or to adjust the temperature for the MORN event. Press PROG.
6. Repeat steps 3-5 for the DAY, EVE and NIGHT events.
7. Repeat steps 3-6 for the weekend (S, SU) program.
8. If needed, repeat steps 2-7 to program the opposite mode (HEAT or COOL).
9. Press
RETURN to exit.
Weekday Weekend
MORN
DAY
EVE
NIGHT
Time: 6:00 pm
Heat: 70˚ F (21˚ C)
Cool: 78˚ F (26˚ C)
Time: 8:00 am
Heat: 62˚ F (17˚ C)
Cool: 85˚ F (29˚ C)
Time: 6:00 am
Heat: 70˚ F (21˚ C)
Cool: 78˚ F (26˚ C)
Time: 10:00 pm
Heat: 62˚ F (17˚ C)
Cool: 82˚ F (28˚ C)
4 Event
Time: 6:00 pm
Heat: 70˚ F (21˚ C)
Cool: 78˚ F (26˚ C)
Time: 8:00 am
Heat: 62˚ F (17˚ C)
Cool: 85˚ F (29˚ C)
Time: 6:00 am
Heat: 70˚ F (21˚ C)
Cool: 78˚ F (26˚ C)
Time: 10:00 pm
Heat: 62˚ F (17˚ C)
Cool: 82˚ F (28˚ C)
5-2 Day Programming– Weekday/Weekend
Factory Settings
