PROGRAMMING
USER SETTINGS
cont.
2.5 Setting Your Energy Saving Programs (continued)
2
PROGRAMMING
USER SETTINGS cont.
2.5 Setting Your Energy Saving Programs – Tips Before Starting (continued)
• This thermostat is preprogrammed with 4 events per day, with times and temperatures recommended by the
Environmental Protection Agency and the U.S. Department of Energy in their ENERGY STAR ® program. These settings
provide efficient energy savings during normal heating and cooling modes of operation. If you wish to use the settings
in the table, no further programming is necessary. Review these time and temperature settings prior to establishing your
personal program settings to maximize your savings, and minimize programming requirements.
MORN
DAY
EVE
NIGHT
Time: 6:00 pm
Heat: 70˚ F (21˚ C)
Cool: 75˚ F (24˚ C)
Time: 8:00 am
Heat: 62˚ F (17˚ C)
Cool: 83˚ F (28˚ C)
Time: 6:00 am
Heat: 70˚ F (21˚ C)
Cool: 75˚ F (24˚ C)
Time: 10:00 pm
Heat: 62˚ F (17˚ C)
Cool: 78˚ F (26˚ C)
Time: 8:00 am
Heat: 70˚ F (21˚ C)
Cool: 75˚ F (24˚ C)
Occupied
4 Event
Unoccupied
Time: 6:00 pm
Heat: 62˚ F (17˚ C)
Cool: 83˚ F (28˚ C)
NOTE:
If the Commercial (BUS) programming mode was selected during the Installer Setup (Installer Guide),
the default program is the 2 events per day shown in the chart above.
Weekday Weekend
MORN
DAY
EVE
NIGHT
Time: 6:00 pm
Heat: 70˚ F (21˚ C)
Cool: 75˚ F (24˚ C)
Time: 8:00 am
Heat: 62˚ F (17˚ C)
Cool: 83˚ F (28˚ C)
Time: 6:00 am
Heat: 70˚ F (21˚ C)
Cool: 75˚ F (24˚ C)
Time: 10:00 pm
Heat: 62˚ F (17˚ C)
Cool: 78˚ F (26˚ C)
4 Event
Time: 6:00 pm
Heat: 70˚ F (21˚ C)
Cool: 75˚ F (24˚ C)
Time: 8:00 am
Heat: 70˚ F (21˚ C)
Cool: 75˚ F (24˚ C)
Time: 6:00 am
Heat: 70˚ F (21˚ C)
Cool: 75˚ F (24˚ C)
Time: 10:00 pm
Heat: 62˚ F (17˚ C)
Cool: 78˚ F (26˚ C)
NOTE: If the 5-2 day programming mode was selected during the Installer Setup (Installer Guide section 4),
the default program will use the weekday and weekend times and temperatures shown above.
• Make sure you select either
HEAT or COOL by pressing the system button as appropriate. You should not enter a
program in the OFF position.
• If Auto Changeover was enabled during installation the user must select either the HEAT or COOL mode.
The thermostat cannot be programmed in the AUTO mode.
NOTE: Once the thermostat has been programmed the user can return to the AUTO mode if desired.
All Days 2 Event All Days
Residential 7 Day Programming
Default Settings
Commercial 2 Event Programming
Default Settings
Residential 5-2 Day Programming–Default Settings
