10

2. System description and Delivery notes

BYK-mac i COLOR measures color traditionally
at five aspecular angles (15°/25°/45°/75°/110°)
with a 45° illumination. Additional color
measurement ”behind” the gloss for color travel of
interference pigments is implemented at -15°.
Besides color, the BYK-mac i uses additional
illuminations to simulate sparkle under 15° /45°
and 75°. Diffused illumination for graininess
evaluation is created by two white coated
hemispheres. Detection is performed by a high
resolution camera situated perpendicular to the
surface.

Additonal out-of-plane sensors detect fluorescent
light excited in the visible range and quantify it by
the Intensity Emisssion Value.

The instrument is operated by the operate button
and the mode-scroll wheel. Functions described
in this manual in regards to effect measurement
are only available with BYK-mac i.

The instrument complies with the following
standards: DIN 5033, 5036, 6174, 6175-2, DIN
EN ISO 11664, SO 7724; ASTM D2244, E308,
E2194, E 1164, SAE J1545.

BYK - mac i 23mm*

7030

BYK - mac i 12mm*

7034

BYK - mac i Sensor 23mm

7031

BYK - mac i Sensor 12mm

7035

Comes complete with:
Multi-angle spectrophotometer, black calibration
standard, white calibration standard with certificate,
cyan and effect checking reference, protective cap,
cleaning set for bottom plate, two light protection
covers, seal replacement kit, *BYKWARE smart-
chart software, docking station with USB cable for
memory transfer, instrument interface cable for
online data transfer, 2 rechargeable Li-ion battery
packs, battery holder, 4 AA batteries, short
instructions, operating manual on CD, carrying
case, training.

System description and Delivery notes
