APPENDIX E
E-8
DWN.BY SCALE APPD.
KC1000 WATER HEATER
IRI GAS TRAIN
SD-A-606
030801
PDR
DATE DATE
NTS
REV.
D
NORTHVALE, NJ 07647 INTERNATIONAL, INC.
AERCO
3/4" NORMALLY OPEN
VENT VALVE
P/N GP-122774
SSOV ACTUATOR W/ P.O.C. SWITCH
P/N 124138
TO AIR
-FUEL VALVE ASS'Y
1 1/4" NPT GAS REGULATOR P/N GP-122415 (NAT. GAS) 123543 (PROPANE)
1 1/2" IRI SSOV
P/N 124137
VENT TO ATMOSPHERE PER ANSI Z223.1 (NFPA54)
HEATER BOUNDARY
SSOV ACTUATOR
W/O P.O.C. SWITCH
P/N 69038
LOW GAS PRESSURE SWITCH
P/N GP-122403
TOP VIEW
