D-2
Appendix D
(cont.)
__________________________
Field Adjust Mode
Display Messages and Defaults (cont.)
Key Display Message Default Range
SYS
START
TEMP
SYS START RELAY
70°F 70°F 32 to 120°F
(Press 2 nd Time) SYS START OPTION
TEMP ONLY
TEMP ONLY TEMP ONLY, or
TEMP AND LOAD
REF
TEMP
BLDG REF TEMP
(When in Indoor/Outdoor
Reset Mode or Remote
Setpoint Mode) 70°F 40 to 220°F
HEADER REF TEMP
(When in Constant
Setpoint Mode) 120°F 40 to 220°F
HDR
TEMP
LIMIT
HDR HIGH LIMIT
220°F 220°F 40 to 220°F
(Press 2 nd Time) HDR LOW LIMIT
40°F
40°F 40 to 220°F
(Press 3 rd Time) HEADER OFFSET
0°F
0°F -5°F to 5°F
SET
POINT
INDOOOR SET POINT
70°F 70°F 50 to 150°F
PROP
BAND INDOOR PROP BAND
00.0°F/°F 00.0°F/°F 0 to 20°F/°F
in 0.5°F/°F
increments
RESET
RATIO
RESET RATIO
1.2°F/°F
(Indoor/Outdoor Reset Mode
Only) 1.2°F/°F 0.3 to 3.0°F/°F in 0.1
increments
FUNCTION NOT VALID
(All Other Modes)
OFFSET OFFSET ENABLE
OFF OFF ON or OFF
OFFSET TEMP
DAY 1: 0 -50 to +50°F
OFFSET ON TIME
DAY 1 00:00 00 to 23 Hours
00 to 59 Mins.
OFFSET OFF TIME
DAY 1 00:00 00 to 23 Hours
00 to 59 Mins.
CONFIG
SYS
FAULT ALARM RELAY
ALL FAULTS ALL FAULTS ALL FAULTS,
NO INTERLOCK,
INTERLOCK 2
INTERLOCK 1
(Press 2 nd Time) FAULT ALARM CLEAR
MANUAL RESET
MANUAL
RESET
MANUAL RESET
or AUTOMATIC
