D-1
Appendix D
_____________________________
Field Adjust Mode
Display Messages and Defaults
Key Display Message Default Range
HDR
TEMP
(Press Once)
RS485 BAUDRATE
9600 9600 2400, 4800, 9600,
14400, 19200
(Press 2 nd Time) MIN SLAVE ADDR
0
0 0 to 127
(Press 3 rd Time) MAX SLAVE ADDR
0
0 0 to 127
(Press 4 th Time) NUMBER NETW BLRS
0 0 0 to 32
(Press 5 th Time) MODBUS CNTL TYPE
Round Robin Round Robin Round Robin or
Broadcast
(Press 6 th Time) NETW BOILER 1
ADDRESS=0
(Repeat for Each Netw Boiler) 0 0 to 127
AIR
TEMP
(Press Once)
RS232 MODE
MODBUS SLAVE MODBUS SLAVE NORMAL or
MODBUS SLAVE
(Press 2 nd Time) RS232 BAUDRATE
9600
9600 2400, 4800, 9600,
14400, 19200
(Press 3 rd Time) MODBUS ADDRESS
128 128 0, 128 to 247
(Press 4 th Time) NETWORK TIMEOUT
60 60 sec. 5 to 240 sec.
(Press 5 th Time) REMOTE SIGNAL
4-20MA 4-20MA 4-20MA or
MODBUS
(Press 6 th Time) MODBUS PASS THRU
DISABLED DISABLED ENABLED or
DISABLED
% LOAD
(Press & Hold)
PERCENTAGE OF LOAD
100% 8 Units 100 % 0 to 100 %
0 to 8 Units
% LOAD
(Press & Release)
SET TIME CLOCK
MONTH: 06 Present month 01 to 12
(Press 2 nd Time) SET TIME CLOCK
DATE: 21
Present day of
month
1 to 31
(Press 3 rd Time) SET TIME CLOCK
YEAR: 03
Present year 00 to 99
(Press 4 th Time) SET TIME CLOCK
DAY: 1 Day one is
Sunday
1 to 7
(Press 5 th Time) SET TIME CLOCK
HOURS: 14
Present time 00 to 23
(Press 5 th Time) SET TIME CLOCK
HOURS: 14
Present time 00 to 23
(Press 6 th Time) SET TIME CLOCK
MINS: 30
Present time 00 to 59
