The WAN Interface Configuration Screen
WPIM-RT1 User’s Guide 3-7
3.2 THE WAN INTERFACE CONFIGURATION SCREEN
This section describes the features of the WAN Interface Configuration
screen. Access the screen by using the arrow keys to highlight the WAN
INT CONFIG command field at the bottom of the WAN Physical
Configuration screen, then press ENTER. The WAN Interface
Configuration screen displays, as shown in
Figure 3-4 .
Figure 3-4 WAN Interface Configuration Screen
3.2.1 WAN Interface Configuration Screen Fields
This section describes the WAN Interface Configuration screen fields.
Interface Number (Modifiable)
Displays the active Interface Numbers. Used to configure the Interface
Numbers that were assigned to the Timeslots on the WAN Physical
Configuration screen.
Max Xmit Unit (Modifiable)
Displays the maximum packet size that can be transmitted on the selected
interface. The default settings for this field depend on the Protocol
Manager chosen.
ProtMgr Iface (Modifiable)
Interface number utilized for the Protocol Manager chosen.
WAN INTERFACE CONFIGURATION
RETURN SAVE
Interface Number: 000
Max Xmit Unit: 0
ProtMgr Iface: [0]
Active Protocol: FR
FR LMI: [ANSI_94]
DLCI Address: 0
DLCI DCP En:
DLCI DCP Stat:
Comp Ratio:
Circuit State: [Invalid]
2750_04
Local Management Flash Image Version: xx.xx.xx
001
002
003
004
005
006
007
008
009
010
011
012
013
014
015
CKT# IF# LID STATE
018
019
020
021
022
023
024
025
026
027
028
029
030
031
032
CKT# IF# LID STATE
016
017 001 Enet UP
PORTS:
[1-32 ]
002 Enet DOWN
