Chapter 3: Local Management
3-2 WPIM-RT1 User’s Guide
3.1 THE WAN PHYSICAL CONFIGURATION SCREEN
To access the WAN Physical Configuration screen, use the arrow keys to
highlight the WAN SETUP menu item, then press ENTER. The screen
shown in
Figure 3-1 displays.
Figure 3-1 WAN Physical Configuration Screen
3.1.1 WAN Physical Configuration Screen Fields
The following sections describe WAN Physical Configuration screen
fields and provide instructions for setting them. The WAN Physical
Configuration screen lets you configure the WPIM or “Physical
Interface.”
To select the WPIM you wish to configure, proceed as follows:
1. Use the arrow keys to highlight the WPIM X command field at the
bottom of the screen.
NOTE
When there is more than one WPIM installed into the host
platform, information for the second WPIM will display next to
WPIM 1. The Line Configuration fields display for the selected
WPIM.
SAVE WAN INT CONFIG RETURN
Type: T1
WPIM #: 1
Mgr Type: [PPP]
Max VCs: 024
Next IF: 003
WAN PHYSICAL CONFIGURATION
T1 Timeslot View:
T1 Line Coding:
T1 Frame Type:
T1 Tx Clock Source:
T1 Line Buildout:
T1 Loopback:
WPIM 1 Timeslot Configuration
000 000 000 000 000 000 000 000 01-08
09-16
17-24
WPIM 1 Line Configuration
000 000 000 000 000 000 000 000
000 000 000 000 000 000 000 000
275002
Local Management Flash Image Version: xx.xx.xx
[WPIM 1]
WPIM 1
[Active]
[B8ZS]
[ESF]
[Loop-Timing]
[0 db]
[None]
REMOTE SETUP
